USA TELECASTERS
Limited Edition Series (2020)
Decal:
ELECTRONICS
Switch: 3-Way / Barrel Switch-Tip
Wiring: Vintage Tone / Tone Bypass / Treble Boost Caps./ 05.uF
Treble Bleed: None
Capacitor: 0.5uf Phonebook / 033uf+33k Resistor (Pos 3 Mod)
PickupConfig: S
BridgePickup: Tim Shaw Designed Esquire Bridge Pickup
Model# 017-0532-XXX
BODY
Wood: Ash
Lacquer: Gloss Nitrocellulose
Shape: Standard Telecaster
Pickguard: 1-Ply Black or White
Serial: Stamped on Bridge / V-serial
NECK
Wood: Maple
Decal: Large Silver Spaghetti w/ Black Trim + "Esquire"
Fretboard: Maple
Neck Lacquer: Gloss Nitrocellulose
Neck Profile: 50's Thick "U"
Headstock: Standard Tele
Nut Material: Natural Bone
Nut Width: 1.630” (41.4 mm)
Scale: 25.5"
Radius: 7.25
#Frets: 21
Fretwire: 6105 Narrow/Tall
Trussrod: Vintage Heel-adjust
MicroTilt: No
ContouredHeel: No
HARDWARE
Bridge Type: Vintage 3-Saddle String-Thru
Bridge Marking: FENDER Pat.Pend + Serial
Saddles: Vintage Solid-Steel Barrel Saddles
Tuners: Vintage Split Shaft Kluson-Style (Pure Vintage Single-Line)
StringTree: 50's Round Button
Knobs: Knurled Dome
Neckplate: 4-Bolt "Fender" 70th Anniversary Commemorative plate
CASE: Deluxe Hardshell Case
Colors:
2-Color Sunburst (803)
White Blonde (801)
Lake Placid Blue (802)
Surf Green (857)
