USA TELECASTERS
American Professional Series: (2020-Today)
Decal:
Model# 011-3962-XXX (Maple)
Model# 011-3960-XXX (Rosewood)
BODY
Wood: Alder
Lacquer: Gloss Urethane
Shape: Standard Telecaster | Belly Cut
Pickguard: 3-Ply Black/White/Black
Serial: Behind Headstock / US-serial
NECK
Wood: Maple
Decal: Goldish Spaghetti w/ Black Border + "Telecaster Deluxe"
Fretboard: Maple /Rosewood
Neck Lacquer: Super-Natural Satin Urethane
Neck Profile: Deep "C"
Neck Thickness .820 - .920 (20.8 - 23.3mm)
Headstock: Standard Tele
Nut Material: Natural Bone
Nut Width: 1.685" (42.8 mm)
Scale: 25.5"
Radius: 9.5"
#Frets: 22
Fretwire: 6105 Narrow Tall
Trussrod: Standard Headstock-Adjust
MicroTilt: Yes
Contoured Heel: Yes
HARDWARE
Bridge Type: VIntage 3-Saddle Cut-Off Bridge
Bridge Marking: Large "Fender" Stamp
Saddles: Vintage Brass Barrel-Saddles
Tuners: Standard Sealed Die-Cast Schaller/Fender Deluxe Tuners
StringTree: Modern "T"
Knobs: Plastic Black or Aged White Witch Hat Knob Amps
Neckplate: 4-Bolt "Fender Corona California"
ELECTRONICS
Switch: 3-Way Switchcraft Toggle (LP Wiring Style)
Wiring: Push/Push on Both Tone for Coil-tap
Treble Bleed: 2X PCB Treble Bleed Circuit
Capacitor: 2X 0.22uf Orange Drop
Pickup Config: HH
Neck Pickup: V-Mod II Double Tap Humbucker
Bridge Pickup: V-Mod II Double Tap Humbucker
CASE: Deluxe Molded Case
Colors:
3-Color Sunburst (700)
MAPLE:
Miami Blue (719)
Mystic Surf Green (718)
ROSEWOOD:
Olympic White (705)
Dark Night (761)
Mercury (755)
