MEXICO TELECASTERS
Fender Standard Died Cast Tuners 09908020100
Fender ClassicGear Vintage Tuners 0990802100
Fender ClassicGear Vintage Staggered 0990802105
Fender Locking Tuners 3 Long / 3 Short post 0990818000
Fender Locking Tuners All Short Posts 0990818105
Fender Locking Tuners 3-3 Round Buttons 0990818500
Kaish 6-In Line Locking Tuners (Economy)
These will drop in without any modification. Installing other models will require drilling new mount holes.
Fender Original tuners can be found cheaper elsewhere. Google the SKU numbers.
Fender 70’s CBS F-Style Tuners 0990822100
Schaller 70’s CBS F-Style Tuners 1058 N, CHR, GLD, BLK
These will drop in without any modification. Installing other models will require drilling new mount holes.
Good Quality ▼
Fender PING Vintage Tuners 0047912049
Fender PING Road Worn Vintage 0997201000
Premium Quality ▼
Fender Pure Vintage Gotoh SD91 0992074000
Fender Gotoh SD91 American Vintage 0992040000
Fender Gotoh SD91 American Vintage Staggered 0992074105
These will drop in without any modification. Installing other models will require drilling new mount holes.
These are not all in existence. Go to my page about these to get more selections.
USA Strats are equipped with Gotoh SD91, Mexico Strats are equipped with PING Vintage tuners.
Model# 014-5212-XXX (Maple)
Model# 014-5213-XXX (Pau Ferro)
Model# 014-5222-XXX (Left Handed) (800,806,850,515)
BODY
Wood: Alder
Lacquer: Gloss Polyester
Shape: Standard Telecaster
Pickguard: Various (See Photos)
Serial: Headstock Rear / MX-serial
NECK
Wood: Maple
Fretboard: Maple /Ebony / Pau Ferro (Dependable Year/Model)
Neck Lacquer: Satin Urethane
Headstock: Standard Telecaster Shape
Neck Profile: Modern "C"
Nut Width: 1.650" (42 mm)
Scale: 25.5”
Radius: 9.5"
#Frets: 22
Fretwire: 6130 Medium Jumbo
Trussrod: Standard Headstock-Adjust
HARDWARE
Bridge: Modern 6-Saddle Flat String-Thru
Bridge Markings: None
Saddles: Standard Chromed Block Saddles
Tuners: Standard Fender/Schaller Die Cast Sealed Tuners ⚙︎
String Tree: Butterfly
Knobs: Knurled Flat-Top
Neckplate: 4-Bolt / "F" Logo
BRIDGE
Switch: 3-Way / Barrel Switch-Tip
Wiring: Standard Wiring B/BN/N
Pickup Config: SS
Neck Pickup: Player Series Alnico 5 Tele Single-Coil
Bridge Pickup: Player Series Alnico 5 Tele Single-Coil
CASE/BAG: None
Colors:
STANDARD COLOR:
3-Color Sunburst (500)
Black (506)
Candy Apple Red (509)
Tidepool (513)
Polar White (515)
Butterscotch Blonde (550)
Capri Orange (582) 2018-2019
Sonic Red (525) 2018-2019
FSR / LIMITED EDITION:
Aged Natural (228)
British Racing Green (518)
Electron Green (075)
Lake Placid Blue (502)
Ocean Turquoise (508)
Oxblood (593) (Anodized Pickguard)
Surf Pearl (549)
Shell Pink (556) FSR: Long & McQuade
CME FSRs:
Burgundy Mist Metallic (566)
Daphne Blue (504)
Olive (598)
Pacific Peach (579) (w/ Shell Pink Hard Shell Case
