USA STRATOCASTERS

Stevie Ray Vaughan Signature

Signature Series (1992-Today)

Stevie Ray Vaughan Signature Stratocaster in 3-Tone Sunburst Rear

Colors:

3 Tone Sunburst (800)

INFO: Fender was in talks with Vaughan to make this model until he sadly died in an accident. Later, His brother continued the collaboration and the guitar saw the light of day at NAMM 1992. A handful first editions has Brazillian Rosewood but was hit with CITES that forced them over to use Pau Ferro. These are extremely rare.

This guitar gives you the SRV feel. However, its a bit far from the original #1:

Tuners are not the same (Original has Schaller 80s Deluxe)
Radius is in the ballpark (Original was worn down to 11”)
Pickups are way hotter than the original ’58 pickups
Pau Ferro Fretboard (Original is Rosewood)

Model# 010-9200-800 (Pau Ferro)

BODY

Wood: Alder

Lacquer: Gloss Polyurethane

Shape: Standard Stratocaster

Pickup Routing: SSS

Serial: Rear Headstock:

SE+6 digits (’92-’94) | SN+6 digits (’95 - ’99)

SZ+6 digits (’00-’09) | US+6 digit (2010-Today)

NECK

Wood: Maple w/Skunk Stripe

Fretboard: Pau Ferro

Fret Markers: White Ivory Dots

Neck Finish: Gloss Urethane

Neck Profile: Custom Thick Oval Shape

Neck Depht .850”–.990”

Headstock: Classic Style Small

Nut Width: 1.650" (42mm)

Nut Material: Synthetic Bone

Scale: 25.5"

Radius: 12”

#Frets: 21

Fretwire: Narrow Jumbo

Trussrod: Single Action, Heel Adjust

Contoured Heel: No

MicroTilt: No

HARDWARE (Gold Plated)

Bridge: 6-Screw Synchronized Left-Handed Tremolo

• Mount Spacing: 2-7/32 (56.4mm)

• String Spacing: 2–7/32 (56.4mm)

Saddle: Bent Steel Saddles “FENDER”

Block: Milled Steel Block

Trem Arm: 10-32 w/Tip

Tuners: Kluson Vintage Split Shaft (No-Line)

String Tree: Butterfly

Neckplate: 4-Bolt Blank

Strap Buttons: Standard

PLASTIC HARDWARE

Pickguard: 3-Ply Black, 8-hole “SRV” Logo Engraved

Rear Cover: 3-Ply Black, Letterbox Slot

Knobs: White, Fender Standard Plastic

PU Covers: White, Standard Plastic

Trem-Arm & Switch Tip: White

ELECTRONICS

Switch: 5-Way Grigsby Grigsby / Std. Tip

Wiring: Modern Standard N/NM/M/MB/B

Pots: 3 Pots

• 1 x CTS Master Volume

• 1x CTS 250k Tone (Neck)

• 1x CTS 250k Tone (Middle)

Pickup Config: SSS

Neck Pickup: CS Texas Special Single-Coil Strat

Middle Pickup: CS Texas Special Single-Coil Strat

Bridge Pickup: CS Texas Special Single-Coil Strat

RWRP: Yes

ACCESSORIES & INFO

CASE: Tweed Case

STRINGS: 010-046 Nickel Plated Steel

Wiring Diagram

Bridge Info

Service Manual

DECAL:
