Richie Sambora Signature (1st Version)

Model# 110-2702-XXX (Maple)

BODY

Wood: Alder

Lacquer: Polyurethane

Shape: Standard Stratocaster | Contoured Upper Horn

Pickguard: 3-Ply White 11-Hole

Pickup Routing: SSH + Mid-Boost Route

Serial: Rear Headstock | SE-Serial

NECK

Wood: Maple w/Skunk Stripe

Fretboard: Rosewood / Maple

Fret Markers: Custom Gold Stars

Neck Finish: Satin Urethane

Neck Profile:  Custom “C”

Neck Depht: .825 - .875

Headstock: Classic Style Small + Tool Bracket w/ Allen Key Rear

Nut Width: 1.650" (42 mm)

Nut Material: Floyd Rose Locking + Retainer Bar

Scale: 25.5"

Radius: 9.5”

#Frets: 22

Fretwire: 6130 Medium Jumbo (.046-.103)

Trussrod: Unknown Rod / Headstock Adjust

MicroTilt: Yes

Contoured Heel: Yes

Neck Stamp: Stamped Date

HARDWARE

Bridge: Floyd Rose Original Double-Locking 2-Point Tremolo

•  Mount Spacing: 2.925” (74.3mm)

•. String Spacing: 2-1/8 (54.0mm)

Saddle: FR Locking (10.8mm)

Block: Floyd Rose Steel Block

Trem Arm: Floyd Rose Screw-on

Tuners: Schaller/Fender Standard Die Cast

String Tree: FR Retainer Bar

Knobs: Standard White Knobs

Neckplate: 4-Bolt “Fender USA”

Strap Buttons: Strap Locks

ELECTRONICS

Switch: 5-Way / White Tip

Wiring: Modern Standard  N/NM/M/MB/B

Pots: 3 Pots

• 1 x CTS  Master Volume
• 1x CTS 250k Master Tone
• 1x CTS 250k Mid Boost Control

AUX 1: Mid-Boost 25db PCB Active + 9V Battery Connector

AUX 2: Push/Push Switch to activate Mid-Boost

Pickup Config: HSS

Neck Pickup: CS Texas Special Single Coil

Middle Pickup: CS Texas Special Single Coil

Bridge Pickup: DiMarzio PAF Pro DP151

CASE: Tweed Case

STRINGS: Factory: 009-042 Nickel Plated Steel
