Model# 010-9300-XXX (Rosewood)

BODY

Wood: Light Ash

Lacquer:  Polyurethane

Shape: Standard Stratocaster

Pickup Routing: ?

Serial: Headstock Rear N+6-Digit or  SZ+6 Digits (2000-)

NECK

Wood: Maple w/ Skunk Stripe

Fretboard: Rosewood

Fret Markers: White Dots

Neck Finish: Satin Urethane

Neck Profile: Custom Narrow “C” Shape

Neck Depht .870”-.930”

Headstock: CBS Large

Nut Width: 1.578" (40mm)

Nut Material: Bone

Scale: 25.5"

Radius: 9.5”

#Frets: 22

Fretwire: 6130 Medium Jumbo (.046-.103)

Trussrod: Bi-Flex Headstock Adjust

Contoured Heel: No

MicroTilt: No

HARDWARE

Bridge: 6-Screw American VIntage Synchronized Tremolo

• Mount Spacing: 2-7/32 (56.4mm)

• String Spacing: 2–7/32 (56.4mm)

Saddle: Bent Steel Saddles (“FENDER” Stamped)

Block: Milled Steel

Trem Arm: 10-32 w/ Tip

Tuners: Kluson Vintage Split Shaft (No-Line)

String Tree: Butterfly

Neckplate: 4-Bolt Blank Plate

Strap Buttons: Strap Locks

PLASTIC HARDWARE

Pickguard: 4-Ply Aged White Pearloid 11-Hole

Rear Cover: 4-Ply Aged White Pearloid, Letterbox Slot

Knobs: White, Fender Standard Plastic

PU Covers: White, Standard Plastic

Trem-Arm & Switch Tip: White

ELECTRONICS

Switch: 5-Way CRL Blade  / Std. Tip

Wiring: Standard Modern (N/NM/M/MB/B)

Pots: 3 Pots

• 1x CTS 250k Master Volume
• 1x CTS 250k Tone (Neck)
• 1x CTS 250k Tone (Middle)

Pickup Config: SSS

Neck Pickup:  CS Texas Special Single Coil

Middle Pickup: CS Texas Special Single Coil

Bridge Pickup: CS Texas Special Single Coil

RWRP: Yes

ACCESSORIES & INFO

CASE: Tweed Case

STRINGS: 010-046 Nickel Plated Steel
