Model# 010-7802 (Maple)

BODY

Wood: Light Ash

Lacquer:  Polyurethane

Shape: Standard Stratocaster

Pickup Routing: ? + Mid-Boost PCB Routing

Serial: Headstock Rear N+6-Digit or  SZ+6 Digits (2000-)

NECK

Wood: Maple w/ Skunk Stripe

Fretboard: Maple

Fret Markers: White Dots

Neck Finish: Satin Urethane

Neck Profile: Soft “V”

Neck Depht .880”-.900”

Headstock:Classic Style Small

Nut Width: 1.650" (42mm)

Nut Material: Bone

Scale: 25.5"

Radius: 9.5”

#Frets: 22

Fretwire: 6230 Vintage Frets (.078-.043)

Trussrod: Bi-Flex Headstock Adjust

Contoured Heel: No

MicroTilt: Yes

HARDWARE

Bridge: American Vintage 6-Screw Synchronized Tremolo

• Mount Spacing: 2-7/32 (56.4mm)

• String Spacing: 2–7/32 (56.4mm)

Saddle: Bent Steel Saddles “FENDER” Stamped

Block: Milled Steel

Trem Arm: 10-32 w/ Tip

Tuners: Kluson Vintage Split Shaft (No-Line)

String Tree: Butterfly

Neckplate: 4-Bolt “Fender Corona California”

Strap Buttons: Strap Locks

PLASTIC HARDWARE

Pickguard: 11-Hole:

• 4-Ply Pearloid White (803)
• Brown Shell (867)

Rear Cover: 1-Ply White, Elongated Holes

Knobs: White, Fender Standard Plastic

PU Covers: White, Standard Plastic

Trem-Arm & Switch Tip: White

ELECTRONICS

Switch: 5-Way CRL Blade  / Std. Tip

Wiring: Standard Modern (N/NM/M/MB/B)

Pots: 3 Pots

• 1x CTS 250k Master Volume
• 1x CTS TBX Master Tone (Neck)
• 1x CTS 250k Master Mid Boost

Aux: Mid Boost PCB Active + 9V Battery

Pickup Config: SSS

Neck Pickup: Lace Sensor Gold Single-Coil

Middle Pickup: Lace Sensor Gold Single-Coil

Bridge Pickup: Lace Sensor Gold Single-Coil

ACCESSORIES & INFO

CASE: Vintage Style Tweed Case

STRINGS: 009-042 Nickel Plated Steel
