Model# 010-6822-805 (Maple)

BODY

Wood: Alder

Lacquer: Polyurethane

Shape: Standard Stratocaster Left-Handed

Pickguard: 3-Ply White

Pickup Routing: SSS

Serial: Rear Headstock | TN+6 digits + “Made in USA”

NECK

Wood: Maple

Fretboard: Maple

Fret Markers: Black Dots

Neck Finish: Gloss Polyurethane

Neck Profile: Standard “C”

Neck Depht .855”-.975 “

Headstock: CBS Large Reversed

Nut Width: 1.650" (42mm)

Nut Material: Bone

Scale: 25.5"

Radius: 7.25”

#Frets: 21

Fretwire: 6150 Medium Jumbo (.046-.103)

Trussrod: Single Action Heel Adjust

MicroTilt: No

Neck Markings: Penciled Date

HARDWARE

Bridge: 6-Screw American Vintage Synchronized Tremolo

• Mount Spacing: 2-7/32 (56.4mm)

• String Spacing: 2–7/32 (56.4mm)

Saddle: Bent Steel Saddles

Block: Milled Steel

Trem Arm: 10-32

Tuners: Schaller “F” Key Tuners

String Tree: Butterfly

Neckplate: 4-Bolt, Hendrix Motif

Strap Buttons: Standard

PLASTIC HARDWARE

Pickguard: 3-Ply White 11-hole

Rear Cover: 1-Ply White, Elongated Holes

Knobs: White, Fender Standard Plastic

PU Covers: White, Standard Plastic

Trem-Arm & Switch Tip: White

ELECTRONICS

Switch: 3-Way Blade / Std. Tip

Wiring: Vintage Standard (N/M/B)

Pots: 3 Pots

• 1x CTS 250k Master Volume
• 1x CTS 250k Tone (Neck)
• 1x CTS  250k (Middle)

Pickup Config: SSS

Neck  Pickup: Reverse Staggered Vintage ’69 Single Coil

Middle  Pickup: Reverse Staggered Vintage ’69 Single Coil

Bridge Pickup:  Reverse Staggered Vintage ’69 Single Coil

ACCESSORIES & INFO

CASE: Deluxe Black Tolex Case w/ Orange lining

FACTORY STRINGS .010 - 046 Nickel Plated Steel

CASE CANDY: Ashtray Cover, Coiled white cable, Strap + brochures

INFO:

5-Way Switch was included in the case

Basically Left handed Stratocaster strung up-side down for right handed players. meaning, Jimi orientation for right handed-players
