Floyd Rose Classic HH (Strat Special)

Model# 010-6700-XXX (Rosewood)

Model# 010-6702-XXX (Maple)

BODY

Wood: Alder

Lacquer: Polyurethane

Shape: Standard Stratocaster

Pickguard: 3-Ply White

Pickup Routing: Swimmingpool

Serial: Rear Headstock | FN + 6 Digits| DZ+7 Digits (2000-)

NECK

Wood: Maple

Fretboard: Rosewood / Maple

Fret Markers: Black or White Dots

Neck Finish: Gloss Urethane

Neck Profile: Modern “C”

Neck Depht: .820 - .890

Headstock: Classic Style Small + Tool Bracket w/ Allen Key Rear

Nut Width: 1.650" (42 mm)

Nut Material: Floyd Rose Locking

Scale: 25.5"

Radius: 9.5”

#Frets: 22

Fretwire: 6130 Medium Jumbo (.046-.103)

Trussrod: Single Action Headstock Adjust / Black Plastic Plug

MicroTilt: Yes

Neck Stamp: Stamped Date

HARDWARE

Bridge: Floyd Rose Original Double-Locking 2-Point Tremolo

• Mount Spacing: 2.925” (74.3mm)

• String Spacing: 2-1/8 (54.0mm)

Saddle: FR Locking 10.8mm

Block: Steel Block

Trem Arm: Floyd Rose Screw-on, No-Tip

Tuners: Vintage Kluson Split Shaft

String Tree: FR Retainer Bar

Knobs: Standard Aged White Knobs

Neckplate: 4-Bolt Slanted “FENDER”

Strap Buttons: Schaller Strap Lock

ELECTRONICS

Switch: Custom 5-Way / White Tip

Wiring: Modern Split  N/NM/M/MB/B

• Pos.1: Full Bridge Humbucker (No Tone Control)

• Pos.2: Front Coil of Bridge and Middle

• Pos.3: Middle Pickup

• Pos.4: Middle and Neck Pickups

• Pos.5: Neck Pickup

Pots: 3 Pots

• 1 x CTS  Master Volume
• 1x CTS 250k Tone (Neck+Middle)
• 1x CTS  Tone (Bridge)

Pickup Config: HSS

Neck Pickup: American Standard Single Coil

Bridge Pickup: Fender DH-1 Humbucker

CASE: Standard Molded Case

STRINGS: Factory: 009-042 Nickel Plated Steel

INFO:

Named Floyd Rose Classic at launch in 1998.

Renamed to Strat Special in January 2002
