Jim Root Signature Stratocaster

Model# 011-4545-705 (Maple)

Model# 011-4545-706 (Ebony)

BODY

Wood: Mahogany

Lacquer: Satin Nitrocellulose

Shape: Super Strat Profile Stratocaster

Countours: Rounded Edged Contours

Pickguard: 11-Hole ABS

   • 3-Ply Black (706)

   • 3-Ply White White (705)

Pickup Routing: HH

Serial: Rear Headstock US + 8 digits

NECK

Wood: Maple

Fretboard: Maple

Fret Markers: None (White Side Dots Only)

Neck Finish: Satin Urethane

Neck Profile: Modern “C”

Neck Depht .850”-.880”

Headstock: Large ‘70s CBS  Style

Nut Width: 1.687" (42.8 mm)

Nut Material: Synthetic Bone

Scale: 25.5"

Radius: 12”-16” Compound

#Frets: 22

Fretwire: 6100 Jumbo (.055-.110)

Trussrod: Bi-Flex Headstock Adjust

Contured Heel: Yes

MicroTilt: No

HARDWARE  (Black)

Bridge: 6-Screw Hardtail String-Thru

  • String Spacing: 2–1/16 (52.4mm)

Saddle: Black Offset Block Saddles

Block: None

Trem Arm: None

Tuners: Schaller/Fender Sealed Locking

String Tree: Ezy-Glyde

Knobs/Covers: Standard Black Plastic

Neckplate: 4-Bolt Blank

Strap Buttons: Schaller Locking

ELECTRONICS (Active System)

Switch: 3-Way / Black Tip

Wiring: Modern Standard  N/M/B

Pots:  1 Pot

• 1 x CTS 25k Master Volume

AUX: 9V Battery

Pickup Config: HH

Neck Pickup: EMG 60 Humbucker Active

Bridge Pickup: EMG 81 Humbucker Active

CASE: Silver Tweed Case w/ Black Ends  and  Deep Red  Interior Lining

STRINGS: Standard Nickel Plated .009-.042 Gauge
