USA STRATOCASTERS
Artist Signature Series (2023-2025)
Colors:
Original Specs for the bridge on this guitar is:
American Vintage Spacing
Mount Spacing: 2-7/32 (56.4mm)
String Spacing: 2-7/32 (56.4mm)
Saddles: 11.2mm
These will fit this guitar: (Vintage String Spacing)
FENDER ORIGINAL: 099-2049-000 / 009-4247-049
CALLAHAM: Vintage S Bridge
KLUSON: KVTS / KVTSLH (Left handed)
ABM: 5050
GOTOH: GE101T (And Many More)
BRIDGE UPGRADE INFORMATION
..Also compatible are the modern bridges:
Vintage/Narrow bridge
Mount Spacing: 2-7/32 (56.4mm)
String Spacing: 2/1-16 (56.4mm)
Saddles: 10.4mm
There are more bridges from other brands that will fit.
If you are uncertain if they will fit this guitar, send me a message for assistance
Violin Burst (830)
Model# 017–0271-830 (Ebony)
BODY
Wood: Semi-Hollow Ash w/ Italian Spruce Top
Binding: Top Bound w/ Black Binding
Lacquer: Gloss Nitrocellulose
Shape: Semi-Hollow Stratocaster w/ F-Hole
Contours: Deep Contours
Pickguard: 3-Ply Black, 11-Hole
Pickup Routing: ?
Serial: Rear Headstock | US + 8 digits
NECK
Wood: Flat Sawn Roasted Flame Maple
Fretboard: Ebony
Fret Markers: None
Neck Finish: Satin Nitrocellulose
Neck Profile: Modern “C”
Neck Depht .820”–.870”
Headstock: Classic Style Small | Matching Head Cap
Nut Width: 1.685” (42.8 mm)
Nut Material: Bone
Scale: 25.5"
Radius: 7.25”–9.5” Compound
#Frets: 22
Fretwire: 6105 Narrow Tall (.054-.094)
Trussrod: Unknown Rod, Headstock Adjust
MicroTilt: No
Contoured Heel: No
HARDWARE
Bridge: 6-Screw American Vintage Synchronized Tremolo
• Mount Spacing: 2-7/32 (56.4mm)
• String Spacing: 2–7/32 (56.4mm)
Block: Steel Block
Saddles: Nickel Plated Bent Steel “FENDER”
Trem Arm: 10-32 w/ Std. Tip
Tuners: Pure Vintage Kluson Style (Single Line) Gotoh
String Tree: Butterfly
Covers/Knobs: Standard Aged White Plastic
Neckplate: 4-Bolt “Fender Suonha” laser engraved
Strap Buttons: Standard Buttons
ELECTRONICS
Switch: 5-Way CRL / Std. Tip
Wiring: Standard Modern (N/NM/M/MB/B)
Pots: 3 Pots
•1 x CTS 250k Master Volume
•1 x CTS 250k Tone Control (Neck+Middle)
•1 x CTS 250k Tone Control (Bridge)
Capacitor .1uf Phonebook (T1+T2)
Treble Bleed: PCB Circuit
Pickup Config: SSS
Neck Pickup: Custom Shop ’69 Single Coil (A5, Unbeveled)
Middle Pickup: Custom Shop ’69 Single Coil (A5, Unbeveled)
Bridge Pickup: Custom Suonha Single Coil (A2, Beveled)
RWRP: No
CASE: Deluxe Blonde Hardshell Case
STRINGS .009 -.042 Nickel Plated Steel
