American Vintage Series (2004)
USA TELECASTERS
Fender Standard Died Cast Tuners 09908020100
Fender ClassicGear Vintage Tuners 0990802100
Fender ClassicGear Vintage Staggered 0990802105
Fender Locking Tuners 3 Long / 3 Short post 0990818000
Fender Locking Tuners All Short Posts 0990818105
Fender Locking Tuners 3-3 Round Buttons 0990818500
Kaish 6-In Line Locking Tuners (Economy)
These will drop in without any modification. Installing other models will require drilling new mount holes.
Fender Original tuners can be found cheaper elsewhere. Google the SKU numbers.
Decal:
Colors:
Cherry Sunburst (830)
Butterscotch Blonde (850)
Black (806)
Fender 70’s CBS F-Style Tuners 0990822100
Schaller 70’s CBS F-Style Tuners 1058 N, CHR, GLD, BLK
These will drop in without any modification. Installing other models will require drilling new mount holes.
Good Quality ▼
Fender PING Vintage Tuners 0047912049
Fender PING Road Worn Vintage 0997201000
Premium Quality ▼
Fender Pure Vintage Gotoh SD91 0992074000
Fender Gotoh SD91 American Vintage 0992040000
Fender Gotoh SD91 American Vintage Staggered 0992074105
These will drop in without any modification. Installing other models will require drilling new mount holes.
These are not all in existence. Go to my page about these to get more selections.
USA Strats are equipped with Gotoh SD91, Mexico Strats are equipped with PING Vintage tuners.
Model# 017-0019-XXX
BODY
Wood: Ash (Chambered with Spruce Cap)
Lacquer: Nitrocellulose
Shape: Standard Telecaster
Pickguard:1-Ply Black / 3-Ply Aged White
Serial: On Bridge / 5-digit
NECK
Wood: Maple
Fretboard: Maple or Rosewood
Neck Lacquer: Nitrocellulose
Neck Profile: U-Shape
Headstock: Standard Tele
Nut Width: 1.650" (42mm)
Scale: 25.5"
Radius: 7.25"
#Frets: 21
Fretwire: 6230 Vintage Frets
Trussrod: Vintage Heel Adjust
MicroTilt: No
ContouredHeel: No
HARDWARE:
Bridge: Vintage 3-Saddle String Thru + Ashtray Cover
Bridge Marking: "Fender Pat.Pend" + Serial
Saddle: Vintage Barrel Brass Saddles
Tuners: Vintage SD91 Vintage Split Shaft ⚙︎
String Tree: 50's Round Button
Knobs: Round Dome Knobs
Neckplate: 4-Bolt Blank Plate
ELECTRONICS
Switch: 3-Way
Wiring: Vintage Wiring
Pos1: Neck
Pos2: Bridge w Tone
Pos3: Bridge w/ No Tone
Pickup Config: SS
NeckPickup: New American Vintage Tele Single-Coil Chrome cover (6.4k)
BridgePickup: New American Vintage Tele Single-Coil (7.3k)
CASE: Vintage Brown Tolex Hardshell Case
INFO:
NAMM Special Edition release based on '52 Reissue Specs
100 where made in Black Color These where solid Ash. No spruce or Chambering
100 Guitars in Butterscotch. Chambered with Spruce Top
100 Guitars in Cherry Red Burst Chambered with Spruce Top
Guitars came with both 6-Saddle and 3-Saddle bridge. Extra bridge was in the case.
