USA TELECASTERS
Limited Edition Series (2018)
Decal:
Fender Standard Died Cast Tuners 09908020100
Fender ClassicGear Vintage Tuners 0990802100
Fender ClassicGear Vintage Staggered 0990802105
Fender Locking Tuners 3 Long / 3 Short post 0990818000
Fender Locking Tuners All Short Posts 0990818105
Fender Locking Tuners 3-3 Round Buttons 0990818500
Kaish 6-In Line Locking Tuners (Economy)
These will drop in without any modification. Installing other models will require drilling new mount holes.
Fender Original tuners can be found cheaper elsewhere. Google the SKU numbers.
Fender 70’s CBS F-Style Tuners 0990822100
Schaller 70’s CBS F-Style Tuners 1058 N, CHR, GLD, BLK
These will drop in without any modification. Installing other models will require drilling new mount holes.
Good Quality ▼
Fender PING Vintage Tuners 0047912049
Fender PING Road Worn Vintage 0997201000
Premium Quality ▼
Fender Pure Vintage Gotoh SD91 0992074000
Fender Gotoh SD91 American Vintage 0992040000
Fender Gotoh SD91 American Vintage Staggered 0992074105
These will drop in without any modification. Installing other models will require drilling new mount holes.
These are not all in existence. Go to my page about these to get more selections.
USA Strats are equipped with Gotoh SD91, Mexico Strats are equipped with PING Vintage tuners.
Model# Unknown
BODY
Wood: Ash Body w/ Kentucky Black Walnut Top
Lacquer: Gloss Nitrocellulose
Shape: Standard Telecaster
Pickguard:1-Ply Anodized Gold 8-Hole Aluminum
Serial: headstock Rear / US-serial
NECK
Wood: Roasted Maple
Fretboard: Roasted Maple
Neck Lacquer: Satin Urethane
Neck Profile: Standard "C"
Neck Thickness .851 - .893 (21.6 - 22.7mm)
Headstock: Standard Tele
Nut Width: 1-11/16" (42.8mm)
Nut: Bone Nut
Scale: 25.5"
Radius: 9.5"
#Frets: 21
Fretwire: 6205 Narrow Tall
Trussrod: Headstock Bi-Flex
MicroTilt: No
Contoured Heel: No
HARDWARE
Bridge: Vintage 3-Saddle String-Thru
Bridge Marking: "Fender Pat.Pend."
Saddle: Vintage Brass Barrel
Tuners: Standard Fender/Schaller Die Cast Sealed Tuners ⚙︎
String Tree: 50's Round Button
Knobs: Knurled Flat Top
Neckplate: 4-Bolt Custom "Fender Willcutt" Stamped Plate
ELECTRONICS:
Switch: 3-Way / Barrel Switch Knob
Wiring Info: Tone Saver High-Pass filter on Volume
Pickup Config: SS
Neck Pickup: CS Twisted Tele Single-Coil (Chrome Cover) (5.9k)
Bridge Pickup: CS Twisted Tele Single-Coil (10.0k)
CASE: Pro Series Tweed Case
INFO
Willcutt Guitars Limited Edition FSR of 50 Guitars made.
Additional 50 Stratocasters was also made.
Colors:
Natural Walnut (821)
