Model# 011-8030-XXX

BODY

Wood: Alder w/ Flame Maple Top

Lacquer: Gloss Urethane

Shape: Standard Telecaster | Belly Cut

Pickguard: 3-Ply Black (8-Hole)

Serial: Headstock Rear / US + 8 digits

NECK

Wood: Maple

Fretboard: Streaked Ebony

Neck Lacquer: Satin Urethane

Neck Profile: Modern "D"

Neck Thickness .830”–.870” (21.1–22.1mm)

Headstock: Standard Tele | Black Painted

Nut Width: 1.685" (42.8mm)

Nut Material: Bone

Scale: 25.5"

Radius: 10”–14" Compound

#Frets: 22

Fretwire: 6130 Medium Jumbo (.106–.036)

Trussrod: Bi-Flex Headstock Adjust

MicroTilt: No

Contoured Heel: Yes

HARDWARE

Bridge: Modern Flat 6-Saddle String-Thru

Bridge Marking: None

Saddle: Chromed Brass Block Saddles

Tuners: Standard Schaller/Fender Locking Tuners / Short Post

String Tree: Modern "T"

Knobs: Knurled Flat Top

Control Plate: Chrome Standard

Strap Buttons: Schaller Strap Lock

Neckplate: 4-Bolt "Fender American ULTRA"

ELECTRONICS

Switch: 3-Way Grigsby Blade / Barrel Switch Tip

Wiring Info: Modern Wiring (N/NB/B)

Potentiometers:

• 1x CTS 250k S-1 Master Volume

• 1x CTS 250k Master Tone

Aux: S-1 Activates Series/Parallel in Middle Pos.

Pickup Config: SS

Neck Pickup: Fender Ultra Noiseless Vintage Pickups

Bridge Pickup: Fender Ultra Noiseless Vintage Pickups

ACCESSORIES & INFO

STORAGE: Elite Molded Case

STRINGS .009-.042 Nickel Plated Steel
