COLORS:
Black
Kalamazoo 1957-1958
Fender PING Vintage Tuners
Fender PING Road Worn Relic Vintage
Fender Locking Tuners 3 Long / 3 Short post 0990818000
Fender Locking Tuners All Short Posts 0990818105
Fender Locking Tuners 3-3 Round Buttons 0990818500
Kaish 6-In Line Locking Tuners (Economy)
These will drop in without any modification. Installing other models will require drilling new mount holes.
Fender Original tuners can be found cheaper elsewhere. Google the SKU numbers.
Fender Standard Died Cast Tuners 09908020100
Fender ClassicGear Vintage Tuners 0990802100
Fender ClassicGear Vintage Staggered 0990802105
Fender Locking Tuners 3 Long / 3 Short post 0990818000
Fender Locking Tuners All Short Posts 0990818105
Fender Locking Tuners 3-3 Round Buttons 0990818500
Kaish 6-In Line Locking Tuners (Economy)
These will drop in without any modification. Installing other models will require drilling new mount holes.
Fender Original tuners can be found cheaper elsewhere. Google the SKU numbers.
BODY:
Body Wood: Solid Mahogany
Binding: Royalite 7-Ply Binding on Top / 5-Ply on Bottom and Headstock
Top Wood: None
Lacquer: Color Lacquer
Finish: Clear Gloss Nitrocellulose
NECK:
Neck Wood: Mahogany
Nut: Nylon (Molded)
Neck Angle: 4°
Headstock Logo: Pearl Inlay Gibson + Split Diamond Ornament
Serial: Yellow Ink Stamped (From 1954)
Binding: Cellulose Nitrate Single Layer
Fretboard Material: Ebony
Inlay: Pearloid Block Inlay
Neck Lacquer: Black Nitrocellulose
Neck Top-Coat: Gloss Nitrocellulose
Neck Profile: Medium Rounded "C"
Nut Width: 1.687" (42.85 mm)
Scale: 24.75" (628.65mm)
Radius: 12"
#Frets: 22
OG Fretwire: NS Low Narrow Frets
Trussrod: Standard Headstock
Bolt-On Type: Glued Set-Neck
HARDWARE:
Bridge Type: Gold ABR-2 Bridge (No Wire Retainer)
Tailpiece: ABR Aluminum Gold (Thin Ear)
Saddles: ABR Gold Plated Brass Saddles
Tuners: Kluson Wafferback / Single Ring Keystone Buttons
PLASTIC:
Knobs: Black Bell Knobs (since 1955)
Pickguard: 3-Ply Black/White/Black
Back Covers: Black Plastic
Switch Plate: Black w/ Gold Lettering
Trussrod Cover: White Plastic with Black Top-Layer / "Les Paul Custom"
ELECTRONICS:
Switch: 3-Way Switchcraft / Cream Tip
Pickup Config: SS (UP : Bridge / MIDDLE: Mid+Bridge / DOWN: Neck)
Wiring: Custom Wiring. Three Volume and One- Master Tone
Capacitor: Sprague Phonebook + Tube Cap 0.2mfd PIO / Bumblebee 0.2mfd PIO
Pots: 500k Centralab
Neck Pickup: Seth Lover P.A.F Humbucker Pickup / Gold Cover
Middle Pickup: Seth Lover P.A.F Humbucker Pickup / Gold Cover
Bridge Pickup: Seth Lover P.A.F Humbucker Pickup / Gold Cover
Case: Black Hardcase w/ Orange Gold Lining
INFO:
Mid-1957 saw the change from Single coil P90 to PAF Humbucker that Seth Lover designed. Almost all models of Gibson made the Humbucker change.The Custom, compared to the LP Standard was upgraded with not just to two buckers, but got a third as well.
The wiring was unorthodox as well.
Rhythm Pos: Selects Neck Pickup Only
Treble Pos: Selects Bridge Only
Middle Pos: Selects Middle and Bridge Pickup
The Bridge pickup was magnet reversed. So selecting middle pos. gave you an Out-of-Phase / Quacky Peter Green like-sound
