USA STRATOCASTERS
Deluxe Strat Plus
Plus Series (1989 - 1998)
Colors:
Scrollable ↓
STANDARD COLORS:
Black (506) (1989/1997-1998)
Natural (521) (1989-1993) Ash Body
Ebony Frost (759) (1990-1992)
Antique Burst (737) (1990-End)
Crimson Frost (761) (1990-1992)
Mystic Black (719) (1993-1996) Replaces 506
Blue Burst (736) (1993-End)
Vintage Blonde (807) (1994-1996)
Crimson Burst (728) (1993-) Replaces 761
Blue Frost (762) (1990-1992)
Firestorm Red (778) (1991-1992)
Shoreline Gold (844) (1997-End)
COLORS 1989 ONLY:
Brown Sunburst (532) (1989)
Pewter (543) (1989)
Gun Metal Blue (580) (1989)
Midnight Wine (575) (1989)
Frost Red (577) (1989)
Arctic White (568) (1989)
Root Beer Metallic (588) (1989)
Blue Pearl Burst (590) (1989)
Black Pearl Burst (591) (1989)
Bahama Green (517) (1989)
Dusty Rose (519) (1989)
ALUMINUM BODIES (1995): 400$ Upcharge
Blue Metal Burst (851)
Violet Metal Burst (852)
Stars & Stripes (853)
Assembled in Fender Arizona
Model# 10-9500-XXX (Rosewood)
Model# 10-9502-XXX (Maple)
BODY
Wood: Alder (with Ash Cap on Top & Bottom)
Lacquer: Polyurethane
Shape: Standard Stratocaster
Pickup Routing: Swimming Pool
Serial:
E+6 digits (1987-1994) (Front under Decal)
N+6 digits (1995-2000) (Headstock Rear)
NECK
Wood: Maple
Fretboard: Maple or Rosewood
Fret Markers: White (RW) / Black Dots (Maple)
Neck Finish: Satin Urethane
Neck Profile: Modern “C”
Neck Depht .810-.880 (+/- Hand finished until 1993)
Headstock: Classic Style Small
Nut Width: 1.687” (43mm)
Nut Material:
- Wilkinson Split Roller Nut (1989-1990)
- Wilkinson Roller Nut (Revised) (1990-1993)
- LSR Roller Nut (1993-1998)
Scale: 25.5"
Radius: 9.5”
#Frets: 22
Fretwire: 6100 Jumbo (.110-.055)
Trussrod: Bi-Flex Headstock Adjust
MicroTilt: Yes
Neck Stamps: Penciled Date
HARDWARE
Bridge:
2-Point American Standard Tremolo (1990)
- 10-32 Arm & Block Saddles
2-Point Deluxe Tremolo (1991-1993)
- Pop In Arm, Block Saddles
2-Point Floyd Rose Mini (1993-1998)
- Pop-In Arm with Hex-Key, FR Locking Saddles
Tuners:
- Sperzel Locking Tuner Chrome or Frosted (1987-mid’88)
- Fender / Schaller Locing Tuners (Frosted) (mid’88 - 1999)
Capacitor .022mfd, 10% 200v
String Tree: None (by factory default)
Neckplate: 4-Bolt | Slanted “Fender”
Strap Buttons: Standard
Other: Hipshot Tremsetter (On most models)
PLASTIC HARDWARE
Pickguard: 3-Ply White / 4-Ply White Shell (On select colors since 1994)
Rear Cover: 3-Ply White / 4-Ply White Shell
Knobs: White, Fender Standard Plastic
PU Covers: White, Standard Plastic
Trem-Arm & Switch Tip: White
ELECTRONICS
Switch: 5-Way CRL / White Tip
Wiring: Modern Standard N/NM/M/MB/B
Pots: 3 Pots
- 1 x CTS 250k Master Volume
- 1x CTS 250k Tone
- 1x CTS 250k /.1 meg. TBX Tone
Pickup Config: SSS
Neck Pickup: Lace Sensor Blue
Middle Pickup: Lace Sensor Silver
Bridge Pickup: Lace Sensor Red (Silver in 1989)
ACCESSORIES & INFO
CASE: Standard Molded Case
DECAL:
