Model# 010-2602-XXX (Maple)

BODY

Wood: Alder

Lacquer: Polyurethane

Shape: Standard Stratocaster | Contoured Upper Horn

Pickguard: 3-Ply Mint Green, 11-Hole

Pickup Routing: SSS + Mid-Boost Route

Serial: Rear Headstock | SN9+ 6 digits or SZ+6 digits (2000-)

NECK

Wood: Maple w/Skunk Stripe

Fretboard: Maple

Fret Markers: Custom Gold Stars Inlay

Neck Finish: Satin Urethane

Neck Profile:  Soft “V”

Neck Depht .830” - .910”

Headstock: Classic Style Small + Autograph rear

Nut Width: 1.650" (42 mm)

Nut Material: Synthetic Bone

Scale: 25.5"

Radius: 9.5”

#Frets: 22

Fretwire: 6230 Vintage Frets

Trussrod: Bi-Flex / Headstock Adjust

MicroTilt: Yes

Contoured Heel: Yes

Neck Stamp: Stamped Date

HARDWARE

Bridge: 6-Screw American Vintage Synchronised Tremolo

• Mount Spacing: 2-7/32 (56.4mm)

• String Spacing: 2–7/32 (56.4mm)

Saddle: Bent Steel “FENDER” Saddles

Block: Standard Steel

Trem Arm: 10-32 w/ Tip

Tuners: Kluson Vintage Split Shaft, Staggered

String Tree: Butterfly

Knobs: Standard Aged White Knobs

Neckplate: 4-Bolt “Fender USA”

Strap Buttons: Schaller Strap Locks

ELECTRONICS

Switch: 5-Way / Std. Tip

Wiring: Modern Standard  N/NM/M/MB/B

Pots: 3 Pots

• 1 x CTS  Master Volume
• 1x CTS 250k Master Tone
• 1x CTS 250k Mid Boost Control

AUX 1: Mid-Boost 12db PCB Active + Battery

AUX 2: Push/Push Switch to activate Mid-Boost

Pickup Config: SSS

Neck Pickup: Fender Hot Noiseless Single-Coil

Middle Pickup: Fender Hot Noiseless Single-Coil

Bridge Pickup: Fender Hot Noiseless Single-Coil

CASE: Classic Vintage Tweed Case

STRINGS: Factory: 010-046 Nickel Plated Steel Super Bullets
