 Model# 017-0302-737 (Rosewood)

BODY

Wood: Alder w/ Quilt Maple Top

Lacquer: Gloss Lacquer

Shape: Standard Stratocaster

Contours: Modern Contours

Pickup Routing: ?

Serial: Rear Headstock | US+8 Digit

NECK

Wood: Flame Maple

Fretboard: Rosewood w/ Rolled Edges

Fret Markers: Pearloid Dots

Neck Finish: Satin Nitrocellulose

Neck Profile: Modern “C”

Neck Depht .820”–.870”

Headstock: Standard Small / Gloss Nitro

Nut Width: 1.685” (42.8mm)

Nut Material: Synthetic Bone

Scale: 25.5"

Radius: 9.5” -12”

#Frets: 22

Fretwire: 6130 Medium Jumbo (.046-.103)

Trussrod: Bi-Flex Headstock Ajust

MicroTilt: No

Contoured Heel: Yes

HARDWARE

Bridge: 2-Point American Standard  Tremolo

• Mount Spacing: 2–7/32 (56.4mm)

• String Spacing: 2–1/16 (52.4mm)

Saddles: Nickel Bent Steel “FENDER”

Block: Copper Infused High Mass Block

Trem Arm: 10-32 w/Tip

Tuners: Schaller/Fender Deluxe Staggered Locking

String Tree: Ezy-Glyde

Neckplate: 4-Bolt  “Fender Corona California” Stamp

Strap Buttons: Schaller Strap Lock

PLASTIC HARDWARE

Pickguard: 3-Ply Parchment, 11-hole

Rear Cover: 3-Ply Parchment, Letterbox Slot

Knobs: Parchment, Fender Standard Plastic

PU Covers: Parchment, Standard Plastic

Trem-Bar & Switch Tip: Parchment

ELECTRONICS

Switch: 5-Way Grigsby Blade / Std. Tip

Wiring: Standard Modern (N/NM/M/MB/B)

Pots: 3 Pots

• 1x CTS  250k Master Volume
• 1x CTS 250k Tone Control  (Neck)
• 1x CTS 250k No-Load Tone Control (Middle + Bridge)

Capacitor .022uf (T1>T2)

Pickup Config: SSS

Neck Pickup: 016730 PB Fender Select Custom Single Coil

Middle Pickup: 016730 PB Fender Select Custom Single Coil

Bridge Pickup: Fender Select Custom Humbucker

ACCESSORIES & INFO

CASE: Custom G&G Case

STRINGS .009-.042 Nickel Plated Steel
