Model# 017-6812-706

BODY

Wood: Chambered Ash

Lacquer: Gloss Urethane

Shape: Standard Telecaster

Pickguard: 1-Ply White (5-Hole)

Serial: Neckplate Laser Engraved / JW + 6-digit

NECK

Wood: Maple

Fretboard: Maple

Neck Lacquer: Natural Satin Urethane

Inlay: Black Dot with Tripple Dots at 12th Fret

Neck Profile: Mid-50's Soft "V"

Neck Thickness .836–.960  (21.2–24.4mm)

Headstock: Standard Tele Matching Lacquer

Nut Width: 1.650" (42mm)

Nut Material: Bone

Scale: 25.5"

Radius: 12"

#Frets: 22

Fretwire: 6130 Medium Jumbo (.106–.036)

Trussrod: Standard Rod Headstock Adjust (1/8" Hex (Allen)

MicroTilt: No

Contoured Heel: Yes

HARDWARE (White Powder Coated)

Bridge: 3-Saddle Custom Chrome "Cut-Off" Vintage Bridge

Vibrato: White Bigsby BS5 Custom w/ Tapered Side Walls

Bridge Marking: "Bigsby"

Saddle: Compensated Steel Barrels

Tuners: Standard Schaller Die Cast Sealed Tuners w/ White Knobs

Tuners Additional: Hipshot Xtender "Drop D" on the E String

String Tree: White Ezy-Glide

Knobs: White Heavy Knurled Flat-Top / Black Amp Knob on Aux Switch

Control Plate: White 3-Pot Plate

Strap Buttons: Non-Slip Classic Style

Neckplate: Contoured 4-Bolt "Laser Engraved "III" Logo + Serial

ELECTRONICS

Switch: 3-Way CRL Blade / White Top-Hat Switch Tip

Wiring: Custom Standard Select (B/M/N)

Potentiometers:

• 1x 500k Master Volume
• 1x 500k Master Tone

Aux1: 3-Position Rotary Toggle:

• Position 1. Kill Switch mode
• Position 2. Standard 3-Way Switching Mode
• Position 3. “Direct-To-Jack”: Controls Bypassed, 3-Position Blade Only

Aux 2: Kill Switch (With Led)

Caps: .022uf

Pickup Config: SSH

Neck Pickup: Custom Jack White CuNiFe Wide-Range Humbucker

Middle Pickup: Custom Jack White JW-90 Single-Coil

Bridge Pickup: Custom Jack White Humbucker

ACCESSORIES & INFO

STORAGE: Black Tolex Case w/ Orange Interior

PRICE: $3.499 (2024)

STRINGS: Nickel Plated Steel .010-.046
