Jeff Beck Signature (1st Version)

Model# 010-9600-XXX (Rosewood)

BODY

Wood: Alder

Lacquer: Gloss Polyurethane

Shape: Standard Stratocaster

Pickup Routing: SSH

Serial: Rear Headstock | N+6 digit  / SN/SZ+6 Digit (’95 - ’97)

NECK

Wood: Maple w/Skunk Stripe

Fretboard: Rosewood

Fret Markers: White Dots

Neck Finish: Satin Urethane

Neck Profile: Thick 50’s “C”

Neck Depht .890” - .970”

Headstock: Classic Style Small

Nut Width: 1.6875" (42.86mm)

Nut Material:

    ↪Wilkinson Split Roller Nut (1991-1992)

    ↪LSR Roller Nut  (1993-2001)

Scale: 25.5"

Radius: 9.5”

#Frets: 22

Fretwire:

    ↪Vintage Frets (1991-1995)

    ↪Medium Jumbo (1995-2001)

Trussrod: Bi-Flex Headstock Adjust

MicroTilt: Yes

Neck Stamp: Stamped Date

HARDWARE

Bridge: 2-Point American Standard  Tremolo

• Mount Spacing: 2–7/32 (56.4mm)

• String Spacing: 2–1/16 (52.4mm)

Saddle: Satin Stainless Block Offset Saddles

Block: Milled Steel Block

Trem Arm: 10-32

Tuners:

• Sperzel Locking Tuners (1992-1994 )

• Schaller Locking Tuners (1994-2000)

String Tree: None

Neckplate: 4-Bolt  “Fender” or “Fender Corona California”

Strap Buttons: Strap Locks

PLASTIC HARDWARE

Pickguard: 3-Ply White, 11-hole

Rear Cover: 3-Ply White, Letterbox Slot

Knobs: White, Fender Standard Plastic

PU Covers: White, Standard Plastic

Trem-Arm & Switch Tip: White

ELECTRONICS

Switch: 5-Way CRL Blade / Std. Tip

Wiring: Modern Standard  (N/NM/M/MB/B)

Pots: 3 Pots

• 1x CTS  Master Volume
• 1x CTS 250k Tone (Neck)
• 1x CTS 250k TBX Tone Control (Bridge & Middle)

Aux: On/Off Switch coil split the Bridge

Pickup Config: HSS

Neck Pickup: Lace Sensor Gold

Middle Pickup: Lace Sensor Gold

Bridge Pickup: Dually Lace Sensor Gold

ACCESSORIES & INFO

CASE: Tweed Case

STRINGS: 009-042 Nickel Plated Steel

INFO:

The first issue Jeff Beck is an entirely different guitar than his current. Mostly the pickups and the thicker neck he prefered at the time.
