USA STRATOCASTERS
Artist Signature Series (8/2001-Today)
Replaces: Jeff Beck Signature (1st Version)
Colors:
BRIDGE UPGRADE INFORMATION
Original Specs for the bridge on this guitar is:
Modern 2-Point Spacing
Mount Spacing: 2-7/32 (2.2”) (56.2mm)
String Spacing: 2-1/16 (52.2mm)
Saddles: 10.4mm
For 2-Point spacing. The higher end bridges out there are universal fit. You can change around any 2-point bridge from Fender. If you require the original bridge to be replaced, please check the spec sheet for this guitar.
American Series (Used on American Standard 1987-2007)
American Standard (Used on American Standard 2008-Today)
Deluxe Series | | American Deluxe
Other popular choices are Gotoh SD510 Series
There are more bridges from other brands that will fit.
If you are uncertain if they will fit this guitar, send me a message for assistance
Olympic White (805)
Surf Green (857)
Model# 011-9600-XXX (Rosewood)
BODY
Wood: Alder
Lacquer: Gloss Urethane
Shape: Standard Stratocaster
Pickguard: 3-Ply Parchment, 11-hole
Pickup Routing: HSH
Serial: SZ+7 Digit (-2009) | US+6 Digits (2010-)
NECK
Wood: Maple
Fretboard: Rosewood
Fret Markers: Ivory Dots
Neck Finish: Satin Polyurethane
Neck Profile: “C” Shape
Neck Depht .850”- .900”
Headstock: Classic Style Small
Nut Width: 1.687" (42.8 mm)
Nut Material: LSR Roller Nut
Scale: 25.5"
Radius: 9.5”
#Frets: 22
Fretwire: 6130 Medium Jumbo (.046-.103)
Trussrod: Bi-Flex Headstock Adjust
Contured Heel: Yes
MicroTilt: Yes
Heel Markings: Stamped Date
HARDWARE
Bridge: 2-Point American Series Synchronised Tremolo
• Mount Spacing: 2–7/32 (56.4mm)
• String Spacing: 2–1/16 (52.4mm)
Saddle: Stainless Steel Satin Offset Block Saddles
Block: Steel Block
Trem Arm: 10-32 w/ Tip
Tuners: Schaller Sealed Locking Tuners (Satin, No logo)
String Tree: None
Knobs/Covers: Standard Aged White
Neckplate: 4-Bolt Slanted “Fender” USA”
Strap Buttons: Standard
ELECTRONICS
Switch: 5-Way CRL / Aged White Tip
Wiring: Modern Standard N/NM/M/MB/B
Pots: 3 Pots
Pickup Config: SSS
Neck Pickup: Fender Hot Noiseless Ceramic Single-Coil
Middle Pickup: Fender Hot Noiseless Ceramic Single-Coil
Bridge Pickup: Fender Hot Noiseless Ceramic Single-Coil
CASE: Vintage Style Tweed Case
INFO:
Just like Clapton, Jeff Beck also took the leap from Lace Sensor to using Fender’s own Noiseless.
The other big change was the neck that was slimmed down to a more comfortable C-Shape
Wiring Diagram
Bridge Info
Service Manual
DECAL:
