USA STRATOCASTERS
American Standard Series (2008-2012)
Replaces: American Series | Successor: American Standard (Version 3)
Model# 011-0400-XXX (Rosewood)
Model# 011-0402-XXX (Maple)
Model# 011-0420-XXX (Left-Hand Rosewood)
Model# 011-0422-XXX (Left-Hand Maple)
BODY
Wood: Alder
Lacquer: Polyurethane
Shape: Standard Stratocaster
Contours: Modern USA Contours
Pickguard: 3-Ply Parchment White, 11-hole
Pickup Routing: HSH
Serial: Rear Headstock | Z+6-digits | US + 8 digits (2010-)
NECK
Wood: Maple
Fretboard: Maple or Rosewood w/ Rolled Edges
Fret Markers: Black or White Dots
Neck Finish: Satin Urethane
Neck Profile: Modern “C”
Neck Depht .830” - .880”
Headstock: Standard Small
Nut Width: 1.685 (42.8 mm)
Nut Material: Synthetic Bone
Scale: 25.5"
Radius: 9.5”
#Frets: 22
Fretwire: 6130 Medium Jumbo (.046-.103)
Trussrod: Bi-Flex Headstock Adjust
MicroTilt: Yes
Contoured Heel: No
Neck Stamp: Stamped Date
HARDWARE
Bridge: 2-Point Synchronised Tremolo
• Mount Spacing: 2–7/32 (56.4mm)
• String Spacing: 2–1/16 (52.4mm)
Block: Tapered High Mass Copper Infused Block
Saddles: Nickel Plated Bent Steel Saddles
Trem Arm: 10-32 Stainless w/Tip
Tuners: Standard Schaller/Fender Die Cast Sealed Staggered
String Tree: Ezy-Glyde
Knobs/Cover: Standard Plastic
Neckplate: 4-Bolt “Fender Corona California” Stamp
Strap Buttons: Standard
ELECTRONICS
Switch: 5-Way Oak Grigsby / Std Tip
Wiring: Standard Modern (N/NM/M/MB/B)
Pots: 3 Pots
Pickup Config: SSS
Neck Pickup: 016730 American Standard Single Coil
Middle Pickup: 016730 American Standard Single Coil
Bridge Pickup: 016730 American Standard Single Coil
ACCESSORIES & INFO
CASE: SKB Hardshell Case
Colors:
3 Tone Sunburst (700)
Olympic White (705) (2008/2010)
Black (706)
Candy Cola (712) (2008-2012)
Mystic Red (794) (2013-2015)
Mystic Blue (795) (2013-2015)
BRIDGE UPGRADE INFORMATION
Original Specs for the bridge on this guitar is:
Modern 2-Point Spacing
Mount Spacing: 2-7/32 (2.2”) (56.2mm)
String Spacing: 2-1/16 (52.2mm)
Saddles: 10.4mm
For 2-Point spacing. The higher end bridges out there are universal fit. You can change around any 2-point bridge from Fender. If you require the original bridge to be replaced, please check the Dervice Manulal of this guitar (if any)
Some bridges that fit:
American Series (Used on American Standard 1987-2007)
American Standard (Used on American Standard 2008-Today)
Deluxe Series | | American Deluxe
Other popular choices are:
Gotoh SD510 Series
Kluson K2PT
There are more bridges from other brands that will fit.
If you are uncertain if they will fit this guitar, send me a message for assistance
3 Tone Sunburst (700)
Olympic White (705) 2008/2010
Black (706)
Candy Cola (712) 2008-2012
Sienna Sunburst (747) 2008 /2010-
Blizzard Pearl (755) 2008-2012
Charcoal Frost Metallic (769) 2008/2010- 2012
Jade Pearl Metallic (719) 2013
Mystic Red (794) 2013-2015
Mystic Blue (795) 2013-2015
Ocean Blue Metallic (773) 2015
Bordeaux Metallic (775) 2015
FSR: (Matchin Headstock)
Daphne Blue (704) 2009 500 Made
Fiesta Red (740) 2009 500 Made
Surf Green (757) 2009 500 Made
FSR:
Wine Red (790) 2012 Hand Stained / Ash Body 50 Made
